MakerBot Quick Tips #6 - Support

MakerBot Quick Tips #6 - Printed Support
The MakerBot and other Fused Deposition Modeling 3D printers have one thing in common: They lay down layers of molten plastic filament which rest upon either a platform or the previously printed layer. The MakerBot Replicator, for example, can print an over hanging feature up to an angle of approximately 45 degrees from vertical. Much more than that, and the extruded plastic would have nothing on which to build, and it would fall down and ruin the print.
There is a solution, and it is the topic of this video: Printed support. The printer can create a temporary support structure, on to which are printed the over hanging layers. The support is removed when the print is complete.
In this video I print the letter "T" to demonstrate how printed support makes it possible to print the over hanging top cross of the "T."
Links to the model files shown in this video:
Parametric Spider Web
Infill: 10%
Layer Height: .2mm
# Shells: 1
Feed Rate: 58mm/sec
Travel Feedrate: 108mm/sec
Extruder Temperature: 240C
Build Platform Temperature: 110C
Material: ProtoParadigm 1.75mm ABS Black
Letters, Numbers & Symbols OH MY! (100mm tall Arial Bold by 10mm Thick)
Infill: 5%
Layer Height: .2mm
# Shells: 1
Feed Rate: 58mm/sec
Travel Feedrate: 108mm/sec
Extruder Temperature: 240C
Build Platform Temperature: 110C
Material: ProtoParadigm 1.75mm ABS Natural
1950's Space Robot
Infill: 15%
Layer Height: .2mm
# Shells: 2
Feed Rate: 58mm/sec
Travel Feedrate: 108mm/sec
Extruder Temperature: 240C
Build Platform Temperature: 110C
Material: ProtoParadigm 1.75mm ABS Natural
