ZTW Spider LITE PRO Series 20A ESC 2-4S F390 MCU Supports Oneshot125 For RC Mini Multirotors
Comes with SimonK bootloader installed, and flashed with newest BlHeli firmware installed and tested. The 20 Amp ESCs BL-Heli ships out pre-programmed and optimized for best performance - pre-configured - OneShot is included/ready, Great for Dampened Light settings.
Continuous Current: 20A
Burst current(10s): 30A
Max. power: 400W
Battery: 2-4 Lipo
Length: 27mm
Width: 14mm
Weight w/wire: 10g
Features:
Active Braking / Damped Light / Comp_PWM Supported
AutoShot (OneShot125 / FastPWM Auto Detect)
Customized to drive all motors without sync issues or cogging.
To enable new features on Baseflight:
- On Configuration tab, check "Enable OneShot" and "Enable FastPWM"
- Scroll down and click "Save"
To enable new features on Cleanflight:
-On Configuration tab, check the "Enabled" box next to "ONESHOT125" Feature
-Scroll down and click "Save"
Package included:
1 x ZTW Spider PRO 20A ESC 2-4S F390
