XL2500-D03/DEVO10/D7E/CC2500 Wireless Module PA + LNA
XL2500-D02 wireless module operates in the 2.4GHz ISM / SRD band free license to use , using TI's CC2500 multi-channel RF transceiver. CC2500 is a low -power wireless applications for the industry's lowest system cost multi-channel wireless products, with a powerful digital processing features , so using only a low-cost MCU can build a high-performance radio systems , including many very useful digital functions , such as an entire packet handling , FIFO buffers, clear channel assessment and wireless wake-up , etc., can be widely used in consumer electronics products ( such as wireless keyboards, mice , game controllers ) , wireless audio transmission ( such as wireless microphones, wireless headphones, wireless speakers ) , etc.
Description:
Item Name: CC2500 module
Operating voltage : 3V ~ 3.6V, recommend close to 3.3V, but can not exceed 3.6V
Output Power: 20dBm (100mW)
Sensitivity: -110dBm@10KBPS
Linear Modules distance: 50-1500 m
Module Size: 17mm * 32mm ( without external antenna )
CC2500 module Typical applications:
access control, time and attendance , logistics
Wireless game controllers ;
Wireless keyboard / mouse ;
Wireless Headphones / speaker / microphone
Automatic meter reading ;
Radio broadcasting ;
Alarm and security systems ;
Home and building automation .
Sports and leisure equipment
Features:
2400-2483.5 MHz band for ISM and SRD -free license to use
Maximum rate of 500kbps, support for 2-FSK, GFSK and MSK modulation
High receiver sensitivity (1.2kbps under -115dBm, 10kbps under -110dBm, 250kbps under -100dBm, 1% packet error rate )
Built-in hardware CRC error detection and multipoint communication address control
Very low energy consumption : TX: In 2 0dBm to 90mA RX: at 250kbps to 100mA;
Programmable output power, maximum output power of 20dBm, the data rate can change between 1.2kbps to 500kbps .
Supports low-power electromagnetic activation function , external interrupt wake , external interrupt or RTC wake up the system
(Support automatic cleanup before transmission channel access (CCA), the carrier sensing system
Fast frequency changes brought about by a suitable synthesizer frequency hopping systems
Software module can be set up address , software programming is very convenient
Standard DIP interfaces for embedded applications
Separate 64-byte RX and TX data FIFO
Few external components , high operational reliability
Package included :
1x CC2500 module
