Walkera QR X350 Pre FPV RC Quadcopter DEVO F12E+G-3D Gimbal+ILOOK++Ground Station+Battery+Charger
QR X350 Pro compare with QR X350 Pre:
Description:
Brand Name: Walkera
Item Name: QR X350 Premium
Version:FPV 4
Transmitter: DEVO F12E
Battery:29.6V(8S) 3000mAh Lipo battery
Gimbal support:3D Gimbal
Camera: FPV iLook+ camera
Quadcopter Color:White
Flight Duration: 20-25 minutes
Radio Transmitter Control Range: 1km
Video Range: 500-800m (FCC)
Weight:6.66kg
SIze:25 x 8 x 22cm
DEVO F12E Encoder 12-channel micro computer system Frequency 2.4GHz DSSS Output Power ≤ 100mW Current Drain Close the video ≤ 300mA(100mW)
View the video ≤ 430mA(100mW) Power Supply Lipo 7.4V /11.1V 1600-3000mAh or 5# battery 8x1.5V or NiMH 8x1.2V 1600-3000mAh Output Pulse 000-2000US(1500US Neutral) G-3D Gimbal Operating Voltage DC 7.4V-28V(recommended 12V,3S lipo battery) Operating Current 500mA-600mA(depends on the voltage supplied and motor power) Operating Temperature -15 °C-65 °C Sensor -axis MEMS gyro and 3-axis MEMS accelerometer Control Accuracy 0.02° Angle Control Range -135°-90°(tilt),-45°-45°(roll) Applicable Camera iLook,iLook+,GoPro Series Size 114.3*97.5*106.6mm(L x W x H) Weight 188g(without camera) iLook+ Video Resolution HD1920*1080P Video Frame Rate 30FPS Video Format MOV Video Compressing H.264 Image Pixel 300 Resolution 4032*3024 Pixels Video Format MJPG Standby Power Loss 1.33W Working Power Loss 1.9W Supply Voltage 3.7V-5V Working Temperature -10°C - 70°C Lens Spec 1/3" Lens Angle 170°(MAX)
Features:
QR X350 Premium:
Dual GPS System. High performance GPS/GLONASS provides redundancy and accuracy in autopilot.
360° Auto Rotation Circle Mode
Follow Me Mode
One Key to Start (Auto take off)
One key to go home
Failsafe returns and lands
Supports G-2D, G-3D, G-3DH,G-3S gimbal.
Supports Waypoint flying mode
Monitor Flight Time, On Screen Display for long distance piloting
System self-diagnostic. Prearm safety checks on receiver, GPS signals , compass , barometer and battery.
Ground Station Control System. Using a mobile phone or tablet, you can change flight modes and set waypoints.
First Person View (FPV) with a professional 12-channel radio, real-time telemetry monitoring aircraft battery voltage, height , distance, flight speed, flight time , GPS coordinates.
Adopting Modular Design,easy to install and connect
Insert 5.8 G image transmit sytem and OSD system, can get image and OSD information easily
DEVO F12E Transmitter:
Telemetry function
Built-in 32 channels to receiver 5.8GHz real-time images
Battery voltage,motor temperature real-time warning
Ergonomic gimbal control knobs
Max transmit distance can reach to 1.5Km
G-3D Gimbal:
Can rotate up and down,turn left and right,you can control the rotation speed
Simple operation,more stable for shooting video
Smart design,aluminium production
High precision brushless motor driving control system
Perfect support iLook,iLook+,GoPro3,GoPro3+ camera
iLook+ :
13MP HD Camera
Low latency and long range FPV
Wide-angle lens camera
Support 5.8 Ghz wireless video link
Support output Micro SD card
Support G-2D and G-3D brushless gimbal
Quick FPV assembly with built-in video transmitter
Compatible with Fatshark and Walkera DEVO F7
Ground Station:
A key to take-off/drop
Route planning
Follow Me
Package Included:
1 x Walkera QR X350 Premium RC Quadcopter
1 x Walkera Devo F12E transmitter
1 x G-3D gimbal
1 x iLook+ camera
1 x Ground station
1 x Battery
1 x E8 Charger
2 x Landing Skids(High and Low)
2 x Blades
1 x Manual
