Tarot ZYX-MINI Mini Flight Controller with GPS PMU Module LED Indicator Combo for FPV Racer
Specification:
Brand name: Tarot
Item name: ZYX-MINI Mini Flight Controller
Working voltage: Flight controller: 4.8-5.5V/ PMU: 7.2-26V
Power consumption: Max 1.75W
Hovering accuracy: Horizontal: 1.5m/ Vertical: 0.5m
Max rotate speed: 150 degree/s
Max inclination angular velocity: 35 degree
Max ascend/descend speed: 6m/s
Working temperature: -10~50 Celsius
Flight controller:
32bit processor, with strong calculating ability.
Built-in damping for sensor, great anti-shock ability.
Plastic protective case, provide overall protection.
Support dual S-BUS receiver
DSM receiver, great signal
GPS Module:
High performance GPS receiver.
High gain antenna
Fast star-searching ability
Accuracy positioning
Intelligent direction control, flying a new look
It is not only properly control the aircraft attitude, but also grow wild in a fun and unique way to control the aircraft fascinating. When using the heading lock, return point locking, points of interest surrounded the aircraft, the flight will no longer face the same direction with the conventional head, you will be a new definition to its pre-flight.
It is support normal receiver, SBUS DSM receiver and satellite receiver.
Flight Range Programmable and No-fly Zone Protect Function:
Under GPS flight mode, the multi-copter will fly inside the setting range only. Under other flight mode, once the multi-copter fly outside the setting range, the auto return-to-launch will be activated. In places near airport and no-fly zone, the flying height and range are restricted.
Size/Weight
Flight controller: 48*40.5*18mm/27.3g
GPS module: 50*50*13mm/26g
PMU: 25.5*9.5*4mm/4.4g
LED indicator: 27*27*8mm/10.5g
USB module: 26*24*7.5mm/5.6g
Package included:
1 X ZYX-Mini flight controller
1 X GPS module
1 X PMU
1 X USB module
1 X LED indicator
2 X Anti-shock double-sided tape
8 X 3P cable
