The new version with adjustable plate:
Overview:
The Super-X Micro Quad is the first Full function micro-sized brushless Quad-Copter,only needs a DSM2 transmitter to assemble with no soldering or gluing needed
Durable full carbon 1.6mm thick one piece 125mm frame, matched with 4 x 6400KV 3 gram brushless motors and 3A ESC,providing double the thrust of its own weight.
Best of all it’s fully plug and play with micro connectors. It comes with 2 sets of 75mm props and full mounting hardware for a quick and easy build. Two 300mah Batteries providing 8 minutes of flight and can easily handle a 600mah for over 12 minutes of flight.
For the FC or flight controller, it is a full featured micro sized MWC. It not only has the normal 6050MPU, but also has a compass and barometer and integrated 7ch DSM2 receiver built in, supporting not only the standard flight modes but altitude hold and carefree modes as well. The FC has support for GPS, OLED and Bluetooth options, and has 6 motor outs for up to a Hex configuration.
This Super –X Micro is perfect for 3D and FPV use,is simply the most advanced and powerful Micro Quad-copter of its size class.
Description:
Item name: Super-X Brushless 125mm Micro Quadcopter
Wheelbase: 125mm
Weight: 38g (without battery)
Motors: MR-03-H 6400KV
ESC: MX-3A
Transmitter: DSM2 compatible(not included)
Battery dimension: 30 x 20 x 6mm
Battery weight: about 8.5g
Flight controller specification:
Integrated DSM2 7ch receiver
Atmega328p
Onboard MPU6050,HMC5883L, BMP180 sensors
Supports IIC-GPS, OLED, BT
6 motor outs that power the esc directly
Onboard DC/DC voltage boost circuit (5v/500ma, for 1s lipo
Onboard linear voltage step-down circuit (5v/500ma, for 2s lipo)
Features:
The first full function micro-sized brushless Quadcopter
Durable full carbon frame
Super lightweight at just 32g
Brushless power system for longevity and power
Full featured micro MWC flight controller
Included FTDI tool for radio and flight modes setup
Integrated DC/DC voltage booster/Step down for 5v 1~2 cell operation
Configuration required(not included):
DSM2 transmitter or module
1S battery charger
Super-x Manual,!
Note: this new version is the adjustable plate
Package Included:
1 x Super-X frame
1 x MWC flight controller
2 x 1S 300mAh 25C lipo battery
4 x MR-03-H brushless motor
4 x MX-3A brushless ESC
8 x propeller
1 x cable set
