Sunnysky X3120 800/920/1100KV Brushless Motor
Specification:
Motor KV 800 920 1100 Stator Diameter 31mm 31mm 31mm Stator Thinkness 20mm 20mm 20mm No.of Stator Arms 12 12 14 No.of Stator Poles 14 14 14 Current(A/10v) 1.3A 1.5A 2.8A Motor resistance 29mΩ 23mΩ 17mΩ Max Continuous Current 51A/10s 54A/10s 63.8A/10s Max Continuous Power 760W 809W 944W Weight 149g 149g 149g Outside Diameter 37.7mm 37.7mm 37.7mm Shaft Diameter 4mm 4mm 4mm Body Length 39.5mm 39.5mm 39.5mm Overall Shaft Length 57.5mm 57.5mm 57.5mm Max Lipo Cell 3S-4S 3S-4S 3S-4S ESC 60A 60A 80A
Recommend Prop(inch):
800KV:APC 13x6.5 , 13x8, 12x8, 12x6
920KV:APC 13x6.5, 13x8, 12x8, 12x6, 11x7, 11x5.5
1100KV:APC 9060, 1060, 11x8, 12x6, 11x7,11x5.5
Package Included:
1 X X3120 Brushless Motor
