Sunnysky X3114 900/1000/1100KV Brushless Motor
Specificaiton:
Motor KV 900 1000 1100 Stator Diameter 31mm 31mm 31mm Stator Thinkness 14mm 14mm 14mm No.of Stator Arms 12 12 14 No.of Stator Poles 14 14 14 Current(A/10v) 1.3A 1.5A 1.7A Motor resistance 40mΩ 29mΩ 23mΩ Max Continuous Current 40A/15s 44A/15s 48A/10s Max Continuous Power 646W 646W 709W Weight 114g 114g 114g Outside Diameter 37.7mm 37.7mm 37.7mm Shaft Diameter 4mm 4mm 4mm Body Length 33.5mm 33.5mm 33.5mm Overall Shaft Length 51.5mm 51.5mm 51.5mm Max Lipo Cell 3S-4S 3S-4S 3S-4S ESC 40A-60A 50A-60A 60A
Recommend Prop(inch):
900KV: APC 13x6.5 ,13x8, 11x5.5, 11x7 , 11x8, 12*6
1000KV:APC 13x6.5, 12x6, 11x5.5, 12x8
1100KV:APC 9060, 1050, 11x5.5, 11x7
Package Included:
1X X3114 Brushless Motor
