Sunnysky X2204S X2204 2300KV Brushless Motor CW / CCW For RC Model
Note:
The Sunnysky X2204S X2204 2300KV Brushless Motor (doesn't provide CW and CCW) has stopped production, more details please turn to this page: http://www.banggood.com/Sunnysky-X2204-2300KV-Brushless-Motor-For-RC-Model-p-945688.html
Description:
Brand: Sunnysky
Item name: X2204 2300KV Brushless Motor
Height: 28mm (to top of shaft)
Width: 27mm
Weight: 21g
Battery (Cell Lipo): 2-3S
KV: 2300
Features:
Long-life Japanese NMB ball bearings.
Efficient Japanese Kawasaki stator steel.
Rare earth magnets stable up to 180℃.
Oxygen free pure copper wires.
CNC machined aluminum case.
Patented balance techniques.
Important Note:
These motors are only proven compatible with ESC's flashed with 5-15-13 SimonK firmware.
Any other firmware or version can cause issues and damage.
Do not run these motors without props and do not use 2.5 bullet connectors (that may cause intermittent connections).
They are high quality motors, but due to their size and high KV, they can be very sensitive to temperature,etc.
We will not be responsible for any damage due to misuse.
Package not include any screws, you need to buy M3 screws by yourselves.
Package not include any screws, you need to buy M3 screws by yourselves.
Package included:
1 x X2204 2300KV Brushless Motor
