SunnySky Edge Racing R2204-2300KV CW/CCW Motor DYS XS 30A ESC Kingkong 5050 3-blade Propeller Combo - 132.99 €

SunnySky Edge Racing R2204-2300KV CW/CCW Motor DYS XS 30A ESC Kingkong 5050 3-blade Propeller Combo
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


SunnySky Edge Racing R2204-2300KV CW/CCW Motor DYS XS 30A ESC Kingkong 5050 3-blade Propeller Combo







Specification:
Item name: SunnySky Edge Racing R2204-2300KV CW/CCW Motor combo

SunnySky Edge Racing R2204 2300KV 2-4s CW/CCW Motor:

Brand Name: Sunnysky
Item Name.: Edge Series R2204-2300KV Brushless Motor
Weight: 26.5g
Motor KV: 2300
Stator Diameter: 22mm
Stator Thickness: 4mm
No.of Stator Arms: 12
No.of Stator Poles: 14
NO-Load Current(A/10V): 1.1
Motor Resistance: 65mΩ
Max Continuous Current: 20A/15S
Max Continuous Power: 300W
Outside Diameter: 28mm
Shaft Diameter: 5mm
Body Length: 17.3mm
Overall Shaft Length: 30.3mm
Max Lipo Cell: 2-4S
Recommend parts (not included):
ESC: 30A
Propeller: HQ5*3 HQ5*4 HQ5*4.5

DYS XS 30A 3-6s Lipo BLheli_S ESC:

Brand Name: DYS
Item Name: XS30A Solder Version
BEC: NO
Weight: 8.65g
Size: 45*16.5*5.8mm
MCU: Silabs EFM8BB2
Input Voltage: 3-6s Lipo
Firmware: BLHeli Bootloader & BLheli_S

7 Pairs Kingkong 5x5x3 5050 5 Inch 3-blade Colorful Propeller CW CCW:

Brand Name: Kingkong
Item Name: 5050 3-blade Propeller
Color: Red, Orange, Yellow, Green, Pink, Black and Purple
Material: PC Fiberglass
Quantity:7 Pairs ( One pair / per color )
Mounting Hole: 5mm
Weight: 143g (Include the box )
Size: 140*140*65mm
Package included:
4 x SunnySky Edge Racing R2204 2300KV 2-4s 2CW/2CCW Brushless Motor
4 x DYS XS 30A 3-6s Lipo BLheli_S ESC
7 Pairs Kingkong 5x5x3 5050 5 Inch 3-blade Colorful Propeller CW CCW
