SunnySky Edge Racing R2204 2300KV 2-4s CW/CCW Brushless Motor For FPV Racing
Note: The "CW / CCW" on our page for selection represent the direction of motor thread, not the direction of rotation
Prop(inch) Volts(V) Amps(A) Thrust(g) Watts(W) Efficiency
Full throttle
Temp*
GF5030
11.1
1.5
100
16.7
6.0
24â
2.5
150
27.8
5.4
3.6
200
40.0
5.0
4.8
250
53.3
4.7
6.1
300
67.7
4.4
7.3
350
81.0
4.3
8.6
400
95.5
4.2
10.5
460
116.6
3.9
Specification:
Brand Name: Sunnysky
Item Name.: Edge Series R2204-2300KV Brushless Motor
Weight: 26.5g
Weight: 26.5g
Motor KV: 2300
Stator Diameter: 22mm
Stator Thickness: 4mm
No.of Stator Arms: 12
No.of Stator Poles: 14
NO-Load Current(A/10V): 1.1
Motor Resistance: 65mΩ
Max Continuous Current: 20A/15S
Max Continuous Power: 300W
Outside Diameter: 28mm
Shaft Diameter: 5mm
Body Length: 17.3mm
Overall Shaft Length: 30.3mm
Max Lipo Cell: 2-4S
Stator Diameter: 22mm
Stator Thickness: 4mm
No.of Stator Arms: 12
No.of Stator Poles: 14
NO-Load Current(A/10V): 1.1
Motor Resistance: 65mΩ
Max Continuous Current: 20A/15S
Max Continuous Power: 300W
Outside Diameter: 28mm
Shaft Diameter: 5mm
Body Length: 17.3mm
Overall Shaft Length: 30.3mm
Max Lipo Cell: 2-4S
Recommend parts (not included):
ESC: 30A
Propeller: HQ5*3 HQ5*4 HQ5*4.5
ESC: 30A
Propeller: HQ5*3 HQ5*4 HQ5*4.5
Feature:
1. High power, high efficiency, light weight
2. Durability: Japanese EZO bearings and hardened shaft
Package Included:
1 x Sunnysky R2204-2300KV Brushless Motor
