Features:
Measures energy (Wh), charge (Ah), power (W), current (A) and voltage (V)
Measures peak Amps, peak Watts ,voltage minimum (sag), peak temperature.
Measures temperature in both Celsius & Fahrenheit (optional temperature probe is necessary)
Auxiliary battery to power watt meter for measurement down to 0V
Accurate & precise – 0.01 A current and 0.01V voltage resolutions
Rugged – handles 50 A continuous and 100 A peak at 60V
Small & light with a tough plastic case
Precision Alu-Chrom current sensing resistor, with only 0.001 Ohms resistance
Factory calibration stores constants in EEPROM to compensate for component tolerances
Application:
Watt Meter measures current, voltage, peak current (Amps), peak power (Watts), minimum voltage (Volts), power (Watts), energy (Watt-hours), charge (Amp-hours) and temperature, peak temperature values for you, in real-time, for the circuit in which you connect it
Now you can stop wondering what's going on with your electric model and get answers that allow you to apply science to your hobby. The precise measurements you collect will help you fine tune your model to get all the performance that you paid for.
-Current through an ESC and motor
-The temperature & peak temperatures of ESC, motor
-Estimate battery's running time for car or airplane
-ESC, BEC and motor efficiencies
-Charge put into and discharge from a battery
-Presence of peak currents that can damage components
-Presence of voltage sags that cause components to operate out of specification
-Why power is lost during acrobatics or extreme conditions
-Effect of gearing and propeller size and shape on power consumption and battery currents Clever hobbyists will discover new applications to further improve electric model performance.
Clever hobbyists will discover new applications to further improve electric model performance.
Parameter
Range or Value
Resolution
Voltage
0-60V (*1)
0.01V
Current
0-100A peak (*2)
0.01A
Power
0-6000W
0.1W
Charge
0-65Ah
0.1mAh
Energy
0-6554Wh
0.1KWh
Temperature
0-150℃/32℉-302℉
1℃/1℉
Auxiliary Power
4.0V-60V
Dimensions
51.3*42.9*13.7mm
Net Weight
42g/1.48oz
Display
26.5*28.5mm LCD
(*1).0V minimum with auxiliary power.
(*2)50A continuous, 100A peak, assumes device’s wires are in free air and attached to connections at or below temperature of 35 flow.
100A operation time depends on ambient temperature and wiring temperature.
You can calibrate all values to zero by pressing “SW” button for more than 3 seconds
Package Included:
1XSKYRC Watt Meter(exclude cable)
