Rcharlance F4 Pro V2 30.5x30.5mm Omnibus F4 Flight Controller OSD BEC AIO 40CH 25/200/600/800mW VTX - 38.00 €

Rcharlance F4 Pro V2 30.5x30.5mm Omnibus F4 Flight Controller OSD BEC AIO 40CH 25/200/600/800mW VTX
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Rcharlance F4 Pro V2 30.5x30.5mm Omnibus F4 Flight Controller OSD BEC AIO 40CH 25/200/600/800mW VTX

Specification:
Brand Name: Rcharlance
Model: F4 Pro + V2

Size: 36x36mm
Mounting Hole: 30.5 x 30.5mm
Net Weight: 12g
Omnibus F4 Flight Controller
Processor: STM32F405

Gyroscope: MPU6000( reserved external gyroscope interface )
Firmware: BetaFlihgt 3.2.0 OMNIBUSF4SD
Input Voltage: 2 - 6s LiPo support
BEC Output: 5V 3A
Support Receiver: PPM, SBUS, IBUS, DSM2/DSMX Receiver ( UART1 )
- Integrated with OSD, support BF Ground Station adjust OSD
Adjust the PID by OSD via remote control
Support Dshot
Support SmartAudio, adjust the VTX by OSD ( UART3 )
- MicroSD card blackbox
- Baro (BMP280)
5.8G 40CH 25/200/600/800mW FPV Transmitter
Frequency: 5362 - 5945MHz
Video Format: NTSC / PAL
Transmitting Power: 25 / 200 / 600 / 800mW switchable
Operating Voltage: DC 7 - 24V
Output voltage: 5V / 450mA
Working Current: 240mA @ 25mW
340mA @ 200mW
520mA @ 600mW
600mA @ 800mW
Transmission Distance: 200m @ 25mW
2KM @ 200mW
4KM @ 600mW
6KM @ 800mW
Remote Software protocol: SmartAudio V2.0
Audio Bandwidth: 6.5MHz
Video Bandwidth: 18MHz
Channel: 40CH
Range: Up to 4km omnidirectional RHCP antenna
Connector: MMCX

Frequency Table:
Channel 1 2 3 4 5 6 7 8
Band A
5865
5845
5825
5805
5785
5765
5745
5725
Band B
5733
5752
5771
5790
5809
5828
5847
5866
Band E
5705
5685
5665
5645
5885
5905
5925
5945
Airwire
5740
5760
5780
5800
5820
5840
5860
5880
Race Band
5658
5695
5732
5769
5806
5843
5880
5917
LowRace Band 5621 5584 5547 5510 5473 5436 5399 5362

Features:
- Standard 30.5x30.5mm Mounting Hole
- Flight Controller AIO FPV Transmitter Module
- Integrates pneumatic module, SD card slot
- Can upgrade 32K gyroscope
- Can use the remote control to set the video transmitter

Package Included:
1x F4 Pro V2 Flight Controller AIO VTX Board
1x MMCX to RP-SMA Female
4x Cable
