Pixracer Autopilot Xracer V1.0 Flight Controller - Mini PX4

Pixracer Autopilot Xracer V1.0 Flight Controller - Mini PX4
Seller: GearBest,


Description:
The new Pixracer ( formerly called XRacer ) is available now and it is fully supported by the Arducopter and PX4 community.
Pixracer is the first autopilot of the new FMUv4 Pixhawk generation. It comes with an upgraded sensor generation, a plug-in WiFi board and a 2MB Flash - a significant improvement compared to former versions.

Specifications:
Item: Pixracer V1.0
MCU: STM32F427VIT6 rev.3
FRAM: FM25V02 - G
Ultra low noise LDOs ( low dropout regulator ) for sensors and FMU ( force management unit )
MPU9250, ICM20608, barometer MS5611, magnetometer HMC5983
Connectors: GPS + I2C, RC - IN, PPM - IN, RSSI, SBUS - IN, Spektrum - IN, USART3 ( TXD, RXD, CTS, RTS ), USART2 ( TXD, RXD, CTS, RTS ), FrSky - IN, FrSky - OUT, CAN, USART8 ( TXD, RXD ), ESP8266 ( full set ), SERVO1 - SERVO6, USART7 ( TXD, RXD ), JTAG ( SWDIO, SWCLK ), PowerBrick ( VDD, Voltage, Current, GND ), BUZZER - LED
Connecotor: JST GH series ( for easy and robust peripheral connections )
Power supply: 5 - 5.5V DC from USB or PowerBrick connector
Dimensions: 36 x 36 x 1.5mm ( 30.5 x 30.5mm spacing, 3.2mm mounting holes )
Pixracer weight: 26g ( including SD card adapter and CNC protective case )

Including Micro SD card, card reader, RGB LED board and ESP8266 802.11bgn WiFi module ( built-in )
Containing a full set of professional flexible silicone cables for almost any peripheral module

Click here to see more details.

Specification

General

Type: Flight Controller

Dimension and Weight

Package weight: 0.082 kg
Package size (L x W x H): 5.00 x 5.00 x 3.00 cm / 1.97 x 1.97 x 1.18 inches

Package Contents

Package Contents: 1 x Pixracer V1.0 Flight Controller, 1 x Accessory, 1 x 4GB SD Card, 1 x SD Card Adapter, 1 x Sticker, 6 x Cable
