Transmitter Parameter:
Weight:80g
Dimension:73*41*14mm
Working Voltage:DC12V
Working Current:≤400mA
Working Frequency:1.2G-1.3G
Working Channels:8CH
Connector: transmitter module side RP-SMA jack, antenna SMA plug
Frequency:1.2Ghz - HC1:1080 HC2:1120 HC3:1160 HC4:1200 HC5:1240 HC6:1280 HC7:1320 HC8:1360(MHz)
Working Power:1500mW
Transmitting Range:1000m~2000m (In Open Fields)
Transmitter accessories:transmitter,antenna,Tx cable,1.25A adapter.
Receiver Parameter:
Weight:115g
Dimension:115*80*21mm
Working Voltage:DC12V
Working Current:≤260mA
Working Frequency:1.2G
Working Channels:12CH
Connector:receiver module side RP-SMA jack, antenna SMA plug
Receiving frequency:1.2GHz - HC1:910 HC2:980 HC3:1010 HC4:1040 HC5:1080 HC6:1120 HC7:1160 HC8:1200 HC9:1240 HC10:1280 HC11:1320 HC12:1360(MHz)
Receiver Accessories:Receiver,antenna,AV cable.(We don't offer adatper for receiver,please use DC 12V 1A adapter.)
The whole set is about 585g.
Package included:
1*1.2GHz 1500mw Transmitter
1*1.2GHz Receiver
1*T*power cable and AV cable set
1*R*power cable and AV cable set
2*2dBi 1.2GHz omni-direction antenna
1*User Manual
