Matek Systems HUBOSD eco X-Type PDB

Matek Systems HUBOSD eco X-Type PDB
Seller: GearBest,


Description:
The HUBOSD offers the high performance and reliability of the four-layer PCB. Integrated with PDB, 5V 12V BEC, 140A current sensor, and STOSD8, it is born for mini FPV quadcopters. No LC filter is needed since the 12V BEC is a linear regulator and no complicated settings are required because of the built-in STOSD8.

Main Features:
- Multifunctional integration: PDB, dual BECs, current sensor, OSD, XT60
- With 2oz thick copper, the 4-layer PCB can handle the maximum current of 4 x 35A
- Two kinds of BECs: DC-DC synchronous buck regulator ( 5V 2A ), linear regulator ( 12V 500mA )
- 140A current sensor

Built-in STOSD8
- Running indicator
- PAL / NTSC auto detection
- Dynamic on-screen information
- Minimum voltage and maximum current recorder
- Automatic flight timer
- Auto detection of battery cells
- Low voltage alarm
- On-screen pilot ID
- Upgradable firmware

Specifications:
Operating voltage: 8 - 12V ( 3 - 5S LiPo )
PDB: 4 x 30A ( 4 x 35A at maximum )
BEC 5V 2A
BEC 12V 500mA, linear regulator
140A current sensor
STOSD8
Size: 51 x 36 x 4mm
Mounting holes: 3mm in diameter, 30.5mm square spacing
Click here to download the user manual.

Note:
1. Developed by Matek independently, STOSD comes into service right after soldering. However, it does not communicate with flight controller, which is different from minimOSD.
2. Please pay attention to the polarity, and do not short.
3. Please use double-sided sticker or nylon posts to separate the carbon fiber frame and the back of the PDB. Otherwise, it is likely that short circuit occurs.
4. 12V BEC also supports 3S input, but the output voltage approximately equals the corresponding voltage minus 1V.

Specification

General

Brand: Matek Systems
Type: Power Distribution Board

Dimension and Weight

Product weight: 0.013 kg
Package weight: 0.040 kg
Product size (L x W x H): 5.10 x 3.60 x 0.40 cm / 2.01 x 1.42 x 0.16 inches
Package size (L x W x H): 6.00 x 5.00 x 1.40 cm / 2.36 x 1.97 x 0.55 inches

Package Contents

Package Contents: 1 x HUBOSD eco X-Type PDB
