IR Infrared Shutter Remote Control Mode Memory For Camera
Description:
Scope of application:SONY,Canon,Nikon,Pentax
Scope of power supply:4.5V-5.5V
Effectiove distance:less than 3m
Mode Types
In all.this camera has 5 kinds of modes and they are:
Mode 1.SONY take picture immediately
Mode 2.SONY camera shooting
Mode 3.Canon take picture immediately
Mode 4.Nikon take picture immediately
Mode 5.Pentax take picture immediately
Mode selection:
Method of mode selection:shorting port TX and RX with jump cap.
First,user turns off power and pups joint TX and RX then ensures that port 5V and GND have been powered.After that blue state indicator light will keep flashing which stands for system has entered the state of mode selection and then it will be out.
After being out.LED will light up again and then will be out in 3 seconds that stands for mode 1 at this moment,if we want to change the mode.We should immediately pull out jumper cap in the 3 seconds which will disconnect TX and RX.After 3 seconds indicator light will keep on which means mode 1 function has been started normally
If mode 1 have not been chose,the indicator light will light up again after 3 seconds and then turn off.At this moment,it stands for entering mode 2 choice.Users also have 3 seconds to choose and the methods are same as that of mode 1.
The choice methods of mode 3.mode 4 and mode 5 as above.
Notice:
If user don't choose mode when they first use the remote controller mode 1 will be chosen by default(SONY take picture immediately).If user have chosen the mode successfully ,the last mode will be chosen automatically after being electrified at nest time for the choice of user having been stored in the remote controller after power failure.If the mode needs to be changed.users will redo according to the steps of mode choice.
Status indicator instruction:
If users don't choose mode,status light will light up shortly after the system being powered on and then run out.After that status light will flicker for indication on the basis of modes which can be chosen in scope of remote control.If system is in mode 1,the light will be on and then will be snuffed out three seconds and subsequently always be bright which means that system has entered the status of current mode function and waited for the signal access.If system is mode 2,the light will be on and then will be snuffed our three seconds,after that it will be on again and then will be snuffed out three seconds and subsequently always be bright which means that system has entered the status of current mode function and waited for the signal access.
Usage:
When IN port receives a pulse signal,meanwhile,its high time is within 0.7ms to 2.2ms.this signal is effective and remote control will send signal according to setting mode as well as control target camera,at this moment the status light will flicker,if signal time is beyond the above scope.system will ignore it and think it as a useless signal.
Package Included:
1 x IR Infrared Shutter Remote Control Mode Memory For Camera
