HMF S550 Asembly Instructions :
HMF S550 Six-axle Rack Multicopter Frame
Description:
Use: Vehicles & Remote Control Toys
For Vehicle Type: Hexacopter
RC Parts & Accs: Principal Axis
Model Number: HMFS550
Material: Carbon Fiber
Wheelbase: 528mm
Weight: About 550g(without gimbal)
Motor suggest: 2212 KV980, 2216 KV880 KV900, 3108 KV720 KV900
Prop suggest: 8038 9047 1038 1045 1047
Battery suggest: 3S-4S 2200mAh-5200mAh
Features:
Similar with dip angle design of S800 rack.
Adopts S800 upward tilt arm design
Plastic injection moduling, ensures hardness and lighter weight ( 10g lighter per arm compare to DJI F550)
Brushless gimbal compatible for FPV
PCB type central plate, ESCs can be soldered directly to the central plate.
Package included:
1 x Hexacopter Frame
1 x Exploded View
