HJ MWC X-Mode Alien Multicopter Quadcopter Frame Kit 3 Colors
Description:
Brand: HJ
Item name: MWC X-Mode Alien Multicopter Quadcopter Frame Kit
Wheelbase: 500mm
Min arm distance: 380mm
Max arm distance: 480mm
Material: glassfiber+ ABS Plastic
Color: Red & White,Red & Black,Black & White
Weight: 485g
Features:
Features:
Center lower plate: 1-4pcs 45 x 45mm flight control board (FF, kk, rabbit, pirate, MWC, etc.)
With extend board, the ESC parallel plates or 4-in-1 ESC can be installed on it.
With mounting holes for Wireless Transmitter, CCD, OSD, GPS antenna, special design for installing NAZA flight controller (long hole left for VELCRO to fix the controller), holes for tall landing skill.
2200 mAh battery can be fixed at the end of the lower plate.
Center upper plate: with cross holes for mounting NAZA GPS and aluminum mounting plate (38 x 38/33 x 33) in front of it for FPV camera.
Transmitter or remote control receiver and other components can be set at the end of the plate.
Arms: similar arms with F450, F550
Biggest propeller can be used: 12-inch, usually we use 10.11 inch ones
Recommended motor: 2212. 2216. 4006. 5005
Recommended Configuration(Not included):
4 x MotorsDYS BX2212 920KV
4 x 30A SimonK ESC
4 x Carbon Fiber 9443 Propellers
1 x MWC MultiWii SE V3.0 Flight Controller
1 x 700TVL 2.8mm camera
1 x 2200mAh 20C 3S 11.1V
Biggest propeller can be used: 12-inch, usually we use 10.11 inch ones
Recommended motor: 2212. 2216. 4006. 5005
Recommended Configuration(Not included):
4 x MotorsDYS BX2212 920KV
4 x 30A SimonK ESC
4 x Carbon Fiber 9443 Propellers
1 x MWC MultiWii SE V3.0 Flight Controller
1 x 700TVL 2.8mm camera
1 x 2200mAh 20C 3S 11.1V
Package included:
1 x Frame Kit (set)
1 x Mounting screws (pack)
