Eachine CCD 700tvl 148 Degree Camera Lens w/ 5.8G FPV Transmitter
Description:
Brand Name: Eachine
Item Name: CCD 700tvl 148° Camera
Angle : 148°FOV 160°DFOV
Pixel : 768(h)*494(v)
Shutter Speed CCD:1/65 ~ 1/100000sec
Power : 5-15V (can be supplied by tranmitter)
Power Consumption: 70mA @5V
Sensor : Sony 1/3” CCD
Video Output : 1.2Vp-p,75ohm, synchronize
Format : PAL /NTSC
Resolution : HD 700TVL
Lens : 2.6mm IR coated FOV: 148°
Working Temp. : -20 to 70C
Camera Size : 32 X 32 X 23.5mm
Lens Size (L X D): 15.3mm X 14mm
Weight : 12g
Package Included:
1 x Camera
1 x Transmitter
1 x Connecting Cable
1 x 5p Cable
Item Name : Transmitter
Item NO.: ET200
Modulation : Broadband FM
Support Video Format : NTSC/PAL
Output Impedance : 75 Ohm
Output Signal : 23~24dBm
Output Power : 200mW
Wireless Channels : 32CH
Working Voltage : 7V~24V
Current :ã190mA
Audio Carrier : 6.5MHz
Antenna Connector : RP-SMA
Dimention : 38mm x 22.5mm x 6mm
Weight : 6g(without antenna) 15g (with antenna)
Frequency:
Band A : 5865,5845,5825,5805,5785,5765,5745,5725
Band B : 5733,5752,5771,5790,5809,5828,5847,5866
Band E : 5707,5685,5665,5645,5885,5905,5925,5945
Band F : 5740,5760,5780,5800,5820,5840,5860,5880
Features:
Super light CCD camera for FPV system
Imaging parameters and wide angle are rigorous debugged for FPV
Imaging parameters and wide angle are rigorous debugged for FPV
Excellent performance highlights and lowlights in day and at night
Ultra-low power consumption abd supper light, extremely suitable for mini quadcopter
Special connecting cable for camera and FPV transmitter, more convenient.
Package Included:
1 x Camera
1 x Transmitter
1 x Connecting Cable
1 x 5p Cable
