DYS SE1806 2550KV CW CCW Brushless Motor Set

DYS SE1806 2550KV CW CCW Brushless Motor Set
Seller: GearBest,
Main Features:
- New design with imported NMB bearing
- N52 magnet and 0.2mm lamination
- Powerful, with 600g thrust to work with 4-inch propellers
- Hollow shaft with screw to fix it
- Especially designed for FPV racers

Specifications

General

Brand: DYS
Type: Motor Set

Motor

KV: 2550
Stator Diameter: 18.0mm
Stator Length: 6.0mm
Shaft Diameter: 3.0mm
Motor Dimensions: 23.0×17.50mm
No. of Cells: 3 - 4S
Max. Continuous Current (A): 18.6A
Max. Continuous Power (W): 312.5W
Internal Resistance: 0.10ohms

Dimension and Weight

Package weight: 0.080 kg
Package size (L x W x H): 15.00 x 8.00 x 6.00 cm / 5.91 x 3.15 x 2.36 inches

Package Contents

Package Contents: 1 x CW Motor, 1 x CCW Motor, 20 x Screw, 4 x Nut
