Detrum Eview Gh4 3 Axis Brushless FPV Gimbal For GoPro 4 3+ 3 Xiaoyi SJcam - 188.99 €

Detrum Eview Gh4 3 Axis Brushless FPV Gimbal For GoPro 4 3+ 3 Xiaoyi SJcam
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


DetrumTech Eview Gh4 3 Axis Brushless FPV Gimbal For GoPro 4 3+ 3 Xiaoyi SJcam






Eview is 3-axis brushless gimbal, suitable for GoPro4, GoPro3+, GoPro3 or cameras with similar size, can be easily mounted on airplane or multi-rotor. You do not need to set any parameters before using. It is very easy to use and supports several work modes, such as panning mode and lock mode.

Specifications

Supported Camera Type

GoPro4, GoPro3+, GoPro3 or cameras with similar size

Input Voltage

3S~6S (11V~25V), Standard: 4S (15V)

Static Attitude Tracking Accuracy

0.01°~0.05°, Standard: 0.02°

Motion Attitude Tracking Accuracy

0.1°~0.5°, Standard: 0.2°

Tilting Angle

-90°~45°, Standard: 0°(horizontal)

Rolling Angle

-38°~38°, Standard: 0°(horizontal)

Panning Angle

-60°~60°

Tilting Increments

0~45°/s

Panning Increments

0~120°/s

Operating Temperature

-10~50℃

Weight

163g (without camera)

Dimension (L×W×H)

98mm×87mm×100mm



Features

3-axis brushless gimbal, suitable for GoPro4, GoPro3+, GoPro3 or cameras with similar size
The gimbal supports two installation modes: hanging installation and vertical installation
Can be easily mounted on airplane or multi-rotor (such as Wiking)
Support various working modes: panning mode, FPV mode and lock mode
Can adjust the tilting angle by hand
There is a Micro USB port on the adapter (down), you can update the firmware via this port
There is a Micro USB port on the camera mounting bracket, you can read the data from the camera’s memory card on-line via this port
Use field oriented control (FOC) Brushless DC Motor Algorithm to get high precision, with static attitude tracking accuracy at 0.01°~0.05°, and motion attitude tracking accuracy at 0.1°~0.5°


Package Included
1 x Gimbal
