Description:
100% Brand new
Dimension: 40mmX40mm
Height: 11.6mm
Weight: 9.6g
Fixing hole spacing: 35mm (It can be changed to 45mm by CRIUS Distribution Board)
Hole diameter: 3mm
Features:
Small size,35x35mm mounting holes
6 input channels for standard receiver and PPM SUM receiver
Up to 8-axis motor output
2 servos output for PITCH and ROLL gimbal system
A servos output to trigger a camera button
A FTDI/UART TTL socket for debug, upload firmware or LCD display
A I2C socket for extend sensor,I2C LCD/OLED display or CRIUS I2c-GPS NAV board
Separate 3.3V and 5V LDO voltage regulator
ATMega 328P Microcontroller
ITG3205 3-axis MEMS gyro
MPU6050 6 axis gyro/accel with Motion Processing Unit
HMC5883L 3-axis digital magnetometer
BMP085 digital pressure sensor
On board logic level converter
Flight mode:
One of the following basic mode
Acro
Level
Alt Hold
Head Lock
Optional mode
HeadFree (CareFree)
GPS Hold (Need GPS receiver + I2C-GPS NAV Board)
GPS Return to home position (Need GPS receiver + I2C-GPS NAV Board)
Package include:
1 x MWC V2.5 SE Flight Control board
2 x 3Pin to 1Pinx3 cable 100mm
1 x 3Pin to 3Pin cable 100mm
