Boscam RX-LCD5802 5.8GHz LCD Diversity Receiver 7 Inch Monitor
Notice: The charger is sold separately. to order it.
Notice: The charger is sold separately. to order it.
Specification:
Built-in 5.8Ghz Dual diversity receiver automatically for best reception
Built-in 2CH 5.8Ghz AV output and 1CH AV input
Built-in high performance Li-POLYMER Battery: 2450mAH/7.4V
Work status OSD display : RSSI indication ; Battery indicator;Channel indication
A key to automatic signal search
Support Chinese and English menu
Screen size:7”
Screen type:TFT LCD Screen/long life, LED backlight
Resolution: 800*480
Brightness: 450cd/m2
View Angle:140/120degree (Horizontal/Vertical)
Size:180mm x 120mm x 50mm(Note:Sunshield height:28mm)
Working Voltage: DC 7~16V
Power Consumption: 650 mA @12V
Battery charging current : 850mA @12V ( max )
Working temperature: -10â~+ 65 â
Connectors:SMA female(outer hole)
Antennas Connectors:SMA male (inner needle)
Features:
Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching
Dual buffered AV outputs
Can receive 2 different channels at the same time
Not affect by 2.4GHz R/C Radios
AV Receiver with Diversity inputs
Small, light weight, durable
4 Bands and total 32 Channels
Built-in battery , easy to carry and outdoor use
A key to automatic signal search,Simple operation
Work status OSD display:Always be aware of the device working condition.
Band and Channel selection
CH
CH 1
CH 2
CH 3
CH 4
CH 5
CH 6
CH 7
CH 8
GROUP
A
5865 MHZ
5845 MHZ
5825 MHZ
5805 MHZ
5785 MHZ
5765 MHZ
5745 MHZ
5725 MHZ
b
5733 MHZ
5752 MHZ
5771 MHZ
5790 MHZ
5809 MHZ
5828 MHZ
5847 MHZ
5866 MHZ
C
5705 MHZ
5685 MHZ
5665 MHZ
5645 MHZ
5885 MHZ
5905 MHZ
5925 MHZ
5945 MHZ
d
5740 MHZ
5760 MHZ
5780 MHZ
5800 MHZ
5820 MHZ
5840 MHZ
5860 MHZ
5880 MHZ
Package Included: Notice: The charger is sold separately. Please to order it.
1 x 7" LCD Screen Receiver Monitor with built in Rechargable Battery
2 x 5.8G Antenna
2 x AV Cable
1 x Charging Cable
1 x Shade Hood
