APM Power Module with 5.3V DC BEC Available with T or XT60
Description:
Input voltage: 6~30V (2~8S)
Output voltage: 5.3V ± 0.1V
Maximum output current: 3A
Maximum current: 90A
Maximum voltage: 30V
6P cable can be directly connected to APM/Pixhawk flight control
Additional 4P rows of pin-free to wire/PIN to connect to another flight control
Dimensions: 25mm x 21mm x 9mm
Weight: 17g (containing all the wire/plug is not included)
Package included
1 x Power Module
