A7105 XL7105-SY-B 2.4G Wireless Transceiver Module
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


A7105 2.4G Wireless Module MD7105-SY Transceiver AA












Description:
Item Name: Transceiver Module

Item

Specification

Remark

Supply voltage

2.5V~3.6V



Current consumption

1uA (typical)   @Sleep mode

0.3mA (typical) @Idle mode

1.7mA (typical) @Stand-by mode

9mA (typical)    @PLL Mode

16mA (typical)  @Rx mode

20mA (typical)  @Tx mode (Pout = 0dBm)



Frequency

2400 – 2483 MHz

ISM band

Transmit output power

0 dBm @ room temperature

typical

Rx sensitivity

-105 dBm (typical) @ 10Kbps mode, Dev = 40 KHz

-100 dBm (typical) @ 250Kbps mode, Dev = 93 KHz

-96 dBm(typical) @ 500Kbps mode, Dev = 186 KHz

BER≦1E-3

Modulation

FSK or GFSK



Transmission distance

About 100meter

BER≦1E-3

Interface

8pin 2.54 mm header



Dimension

23.3mm(L) x 12.5mm(W) x 5mm(H)

Not include the connector

Operating temperature

-40 ~ 85 ℃





Interface:

Pin No.

Symbol

Function Description

Remark

1

GND

Ground



2

Vin

RF Module Supply Votlage Inpute

2.5V--3.3V

3

 NC

NO Connection



4

SCS

SPI Chip Selection



5

SCK

SPI Clock



6

SDIO

SPI Data I/O



7

GIO1

General Purpose I/O1



8

GIO2

General Purpose I/O 2





Features:
XL7105-SY is made by adopting high performance 2.4G wireless transceiver chip A7105 of Taiwan Shengke (AMIC)
Working in 2400-2483M international opened ISM band
The biggest transmission power is 0 dBm(1 mW )500 KBPS
The highest RX sensitivity is -99 dBm @ 250 KBPS,
The distance is as far as 120M
Built-in ID CODE WORD in IC,support CD (carrier detect), FEC error correction
SPI interface, independent 64 bytes RX and TX FIFO.
Cost performance is higher than NRF24L01 and CC2500

Note: this module needs 3.3V power supply, can use voltage chip to reduce the voltage.


Package Included:
1 x Transceiver Module
