DJI Phantom 4 - Tested Video Review











Aircraft

Weight (Including Battery) 1380 g
Max Ascent Speed 6 m/s (Sport mode)
Max Descent Speed 4 m/s (Sport mode)
Max Speed 20 m/s (Sport mode)
Max Service Ceiling Above Sea Level 19685 feet (6000 m)
(Software altitude limit: 400 feet above takeoff point)
Max Flight Time Approx. 28 minutes
Operating Temperature Range 32° to 104° F (0° to 40° C)
Satellite Systems GPS / GLONASS
Hovering Accuracy Vertical:
+/- 0.1 m (when Vision Positioning is active) or +/-0.5 m
Horizontal:
+/- 0.3 m (when Vision Positioning is active) or +/-1.5 m

Obstacle Sensing System

Obstacle Sensory Range 2 - 49 feet (0.7 - 15 m)
Operating Environment Surface with clear pattern and adequate lighting (lux > 15)

Camera

Sensor 1/2.3” Effective pixels:12 M
Lens FOV ( Field Of View ) 94° 20 mm ( 35 mm format equivalent ) f/2.8 focus at ∞
ISO Range 100 - 3200 ( video ) 100 - 1600 ( photo )
Electronic Shutter Speed 8 s to 1/8000 s
Max Image Size 4000×3000
Still Photography Modes Single shot
Burst shooting: 3 / 5 / 7 frames
Auto Exposure Bracketing ( AEB ): 3 / 5 bracketed frames at 0.7 EV Bias
Time-lapse
HDR
Video Recording Modes UHD: 4096×2160 (4K) 24 / 25p
3840×2160 (4K) 24 / 25 / 30p
2704×1520 (2.7K) 24 / 25 / 30p
FHD: 1920×1080 24 / 25 / 30 / 48 / 50 / 60 / 120p
HD: 1280×720 24 / 25 / 30 / 48 / 50 / 60p
Max Video Bitrate 60 Mbps
Supported File Systems FAT32 ( ≤ 32 GB ); exFAT ( > 32 GB )
Photo JPEG, DNG ( RAW )
Video MP4 / MOV ( MPEG – 4 AVC / H.264 )
Supported SD Cards Micro SD, Max capacity: 64GB. Class 10 or UHS-1 rating required
Operating Temperature 32° to 104° F ( 0° to 40° C )

Charger

Voltage 17.4 V
Rated Power 100 W

Gimbal

Controllable Range Pitch: -90° to +30°

Vision Positioning System

Velocity Range ≤10 m/s ( 2 m above ground )
Altitude Range 0 - 33 feet (0 - 10 m)
Operating Range 0 - 33 feet (0 - 10 m)
Operating Environment Surfaces with a clear pattern and adequate lighting (lux > 15)

Remote Controller

Operating Frequency 2.400 GHz to 2.483 GHz
Max Transmission Distance FCC Compliant: 3.1 mi ( 5 km );
CE Compliant: 2.2 mi ( 3.5 km )( Unobstructed, free of interference )
Operating Temperature 32° to 104° F ( 0° to 40° C )
Battery 6000 mAh LiPo 2S
Transmitter Power ( EIRP ) FCC: 23 dBm; CE: 17 dBm
Operating Voltage 7.4V @ 1.2A

Intelligent Flight Battery ( PH4 - 5350 mAh -15.2 V )

Capacity 5350 mAh
Voltage 15.2 V
Battery Type LiPo 4S
Energy 81.3 Wh
Net Weight 462 g
Operating Temperature 14° to 104° F ( -10° to 40° C )
Max Charging Power 100 W
