Diatone NAZE32(B) REV6 Plus 6DF & OSD Flight Controller STM32 F103 Supports Baseflight For RC Multirotors
Description:
Naze32 OSD based on Naze32 Rev6 add OSD function, OSD can show the flight controller current battery voltage, flight time, attitude and etc information, easier for pilot to control the flight details and prevent battery over discharge damage.
Features:
Easy to use, popular for beginners
Integrated OSD function, grasp the flight information all times
Can use integrated OSD, also can use off-board OSD equipment
High-performance Six-Axis Sensor guarantee super stability
Battery voltage monitoring
Built-in FrSky telemetry converter
Modern 32-bit processor (STM32 F103) running at 3.3V/72MHz.
Onboard USB for setup and configuration
Modern GUI for all operating systems, Baseflight Configurator
Note: If you do not have a CPPM enabled Receiver, you will also need to purchase the RC Breakout Cable.
Specifications:
Six-Axis: MPU6500
Compass: NO
Barometer: NO
Size: 36*36mm
Weight: 5.5 grams
Package included:
1 x Naze32 Rev6(B) 6DF&OSD Flight Controller
9 x Pins set
2 x 2 pin Jumper Cap
1 x Wire
