CC3D Flight Controller 8Pin Connection Cable Set ReceiverPort
Description:
Item name: CC3D Cable Set
Color
Function
JST-SH Pin
Servo connector plug
Black
Ground
1
1
Red
Power to RC RX-(VCC Unregulated) 4.8V-15V
2
1
White
PWM signal 1 or combined PPM
3
1
Blue
PWM signal 2
4
2
Yellow
PWM signal 3 or PWM output channel 7
5
3
Green
PWM signal 4 or PWM output channel 8
6
4
Orange
PWM signal 5 or PWM output channel 9
7
5
Purple
PWM signal 6 or PWM output channel 10
8
6
S.BUS
Black
1
GND
GND
GND
GND
Red
2
4.8V-15V
PWR out (VCC unregulated)
PWR out (VCC unregulated)
PWR out (unregulated star)
Blue
3
3.3V
TX
SCL
Orange
4
3.3V (5V Tolerant)
RX
SDA
TX (signal)
Package included:
1 x CC3D Cable Set
